Goldmedal Air 2 Module 4 Way Double Door Distribution Board - 07141

Brand: Goldmedal
Product Code: Goldmedal-07141
Product Name: Goldmedal Air 2 Module 4 Way Double Door Distribution Board-07141
4 Way-Air DB (Metal) DB IP43 Tv/Tel. SPN.
Conforms to IS 8623-1 and 3, IEC 61439-1 and 3.
Reversible Door for IP-43 and IK -09 Dbs.
Suitable for Surface and Flush Mounting.
Enclosure is made up of CRCA Sheet steel, RAL 9002 Powder coated, Ready to use DBs- includes 100A insulated Phase Bus-bar, Shrouded Neutral /Earth bar with Conditional Short Circuit Rating and having telephone socket and TV co-axial socket.
This DB's kit includes high integrity accessories like Cement spill protector sheet, Colour-coded inter connecting wire set, Cable ties ,Blank Module, Sticking Saddles, Circuit identification labels.
There is a provision for-
1)SPN:DP MCB /Isolator/ RCCB/RCBO as incomer and SP MCBs as outgoings.
2)TPN:FP MCB /Isolator/ RCCB/RCBO as incomer and SP/TP MCBs as outgoings.
Series: Air
Color: White
